Description
Biological Microscope YR0242-M // YR0242-T is an advanced optical device designed to meet the rigorous demands of modern laboratories and educational institutions. This versatile microscope offers monocular, binocular, and trinocular viewing options, catering to various observational needs. Equipped with a quadruple nosepiece and an integrated double-layer mechanical stage, it provides precision and ease in specimen examination. The inclusion of an Abbe condenser, a high-brightness 3W LED that is brightness adjustable, and an infinity plan and achromatic optical system ensures superior image clarity. These features make it an ideal choice for both professional researchers and students alike.
Market Price
In the market, the Biological Microscope YR0242-M // YR0242-T typically falls within the price range of 340 USD to 900 USD. This range provides potential buyers with a competitive pricing view for high-quality microscopes, making it an accessible investment for educational and research purposes.
Frequently Asked Questions
What type of lighting does the microscope offer? The YR0242 series allows you to choose between halogen and LED lighting, accommodating different user preferences.
Can the trinocular version accommodate cameras? Yes, the Seidentopf Trinocular is compatible with C-Mount adapters, allowing video integration.
Advantages and Disadvantages
Advantages: This microscope provides high optical performance, flexibility with its multiple head options, and a robust build that suits diverse applications.
Disadvantages: It may require some initial setup and calibration for optimal performance, which could be challenging for beginners.
Use of the Product in the Field
The Biological Microscope YR0242-M // YR0242-T is widely used in laboratories for specimen analysis and educational demonstrations. Its precision and adjustable illumination make it suitable for detailed biological and chemical studies.
Recommendations
To ensure longevity and optimal performance, regularly clean the lenses with a microfiber cloth and store the microscope in a dust-free environment when not in use. Consider enrolling in Kalstein Plus for automated price quotations and support.
Features
- Monocular, binocular, trinocular, and teaching head options.
- Quadruple nosepiece with precise click stop.
- Integrated double-layer mechanical stage.
- Abbe condenser with adjustable brightness.
- Infinity plan and achromatic optical system.
Technical Specifications
| Model No. | YR0242-M | YR0242-B | YR0242-T |
| Video Adapter | —— | C-Mount 0.3x | —— |
| Power Supply Type | AC 110V-240V | —— | |
| Transmit Light | Halogen 6V20W or LED Optional | ||
| Light Source Type | Halogen | ||
| Condenser N.A. | 1.25 | ||
| Condenser Type | Abbe | ||
| Condenser Features | Rack & Pinionↆ↑, Filter Holder, Center Adjustable | ||
| Focusing Scale | 0.002mm | ||
| Focusing Range | 36mm | ||
| Focusing Type | Coaxial Coarse & Fine | —— | |
| Focusing Features | Safety Stop Screw Tension Adjustable | ||
| Working Stage Moving | 75*50mm | ||
| Working Stage Size | 132*142mm | ||
| Working Stage Type | 2 Layers Mechanical | ||
| Objective | Achromatic 4x, 10x, 40x(S), 100x(O,S) | ||
| Objective Type | Achromatic | ||
| Nosepiece Holes | 4 Holes | ||
| Nosepiece Features | Inward | ||
| Eyepiece | WF10x/18mm | ||
| Eyepiece Diameter | 23.2mm | ||
| Head Interpupillary | 54~75mm | ||
| Head Rotation | Head Rotate 360° | —— | |
| Head Inclination | 30° | —— | |
| Head Type | Monocular | —— | Seidentopf Trinocular |
| Standard Magnification | 40x-1000x | —— | |
| Optical System | Achromatic | ||
| Standard Function | BF | —— | |
