Description
The Veterinary High-frequency Mobile C-arm System YR06165 is a state-of-the-art imaging device designed for various veterinary procedures such as orthopedics, general surgery, pain management, and traumatology. This advanced C-arm system integrates a digital acquisition and processing system, offering enhanced convenience and efficiency during operations. The high-quality combined HF-HV X-ray generator significantly reduces X-ray exposure, ensuring the safety of both the operator and the patient. Its electric rotatable adjustable collimator and a unique hand-held remote controller provide ease of use, while the graphical, colorful LCD touch screen interface offers a modern and user-friendly experience.
Market Price
The price of veterinary high-frequency C-arm systems like the YR06165 generally falls within the range of $52,000 to $53,300 USD. This cost reflects the cutting-edge features and technology that make it an invaluable asset for veterinary practices aiming to provide exceptional care.
Frequently Asked Questions
- What types of veterinary procedures can this equipment be used for? The YR06165 is suitable for orthopedic, general surgery, pain management, and trauma-related procedures in the veterinary field.
- How does this system minimize radiation exposure? It features a high-quality HF-HV X-ray generator designed to reduce radiation exposure levels.
- Is the system user-friendly? Yes, it includes a touch screen interface and remote controller for easy operation.
Advantages and Disadvantages
Advantages: The YR06165 offers reduced radiation exposure, a user-friendly interface, and high-resolution imaging, making it ideal for detailed and safe veterinary diagnostics. Disadvantages: The initial investment can be considerable, which may not be ideal for smaller practices with limited budgets.
Use of the Product in the Field
In practical settings, the Veterinary High-frequency Mobile C-arm System YR06165 is used extensively in veterinary clinics and hospitals. Its mobility allows veterinarians to perform imaging procedures directly in operating rooms or examination rooms, enhancing the workflow and minimizing patient movement.
Recommendations
To maximize the YR06165’s functionality, it is recommended to regularly calibrate and maintain the equipment according to the manufacturer’s guidelines. Training staff on the system’s operation will further ensure optimal results and prolonged device longevity.
Features
- Integration of a digital acquisition and processing system
- High-quality HF-HV X-ray generator
- Electric rotatable adjustable collimator
- Hand-held remote controller
- Graphical LCD touch screen interface
- Toshiba image intensifier for high-definition imaging
- Automatic tracking for optimal image settings
Technical Specifications
| Model | YR06165 | |
|
Electrical Performance
|
High Frequency Inverter Output Power | Output Power: 5kW Inverter Frequency:40kHz |
| Automatic Fluoroscopy | Tube Voltage:40kV～120kV automatic adjustment Tube Current:0.3mA～4mA automatic adjustment |
|
| Manual Fluoroscopy | Tube Voltage:40kV～120kV continuous adjustment Tube Current:0.3mA～4mA continuous adjustment |
|
| Pulse Fluoroscopy | Tube Voltage:40kV～120kV continuous adjustment Tube Current:0.3mA～30mA continuous adjustment |
|
| Photography Tube Voltage, mA, mAs |
40 kV~120 kV 25-100mA 1-180mAs |
|
| Film Holder Size | 200mm×250mm(8″×10″) or 250mm×300mm (10″×12″) |
|
| X-ray Tube | X-Ray Tube Special for High Frequency | Fixed anode Dual-focus, small focus: 0.6, large focus: 1.8mm Thermal capacity: 35.5KJ (47KHU) |
|
Video System
|
Image Intensifier | Toshiba 9” Image Intensifier 3-fireds |
| CCD Video camera | Medical Mega-pixels digital CCD camera | |
| 24’’ LCD monitor | 1920×1080, 60Hz | |
| Digital workstation | Storage without damage, multi-images display, image W/L real time adjustment, grayscale switch, region of interest balance, GAMMA correction, flip, noise reduction, intensifying, smoothing, sharpening, compression, zoom in, measurement, remark, picture-text typeset print, expert template, DICOM image transmit, DICOM image print, cineloop, image imprinting, Worklist registration etc. | |
|
Structure
|
Directive wheel | Direction wheel 360° rotation, main wheel ±90° rotation |
| C-arm | Electric Ascending & Descending of pillar movement: 400mm Forward and Backward Movement: 200mm Revolution around Horizontal Axis: ±180° Revolution around Vertical Axis: ±15° Slip on orbit: 120°(+90°～ -30°) Monitor Rotation: 300° SID: 960mm Opening: 760mm Arc depth: 640mm |
|
