Description
The Digital Intelligent Ultrasonic Homogenizer Processor Sonicator YR05837 // YR05839 is an essential instrument for labs that demand precision and efficiency in processing solid-liquid samples. Prominent for its capabilities such as cell lysis, emulsification, and nanoparticle dispersion, this ultrasonic processor accelerates chemical reactions with its advanced digital interface and automated controls. Adjusting ultrasonic power from 0 to 100% allows customization for specific sample needs. With a 3.2-inch LCD touch screen and the capacity to store up to 8 data sets, this equipment ensures seamless operation and meticulous monitoring.
Market Price
The Intelligent Digital Sonicator YR05837 // YR05839 falls within a price range of $2,300 to $3,800 USD, contingent on additional features such as optional probes and cooling systems. This price reflects the advanced technology and superior performance of this sonicator compared to other ultrasonic homogenizers in the market. If you’re eager to explore its benefits, we encourage you to request a quote or generate one automatically through our Kalstein Plus platform, streamlining your decision-making process.
Frequently Asked Questions
- What types of samples can this device process?
The YR05837 // YR05839 is suited for a wide array of samples, including animal cells, plant cells, nanoparticles, emulsions, and soil samples.
- Is it safe for sensitive samples?
Yes, its precise power and temperature control features prevent any thermal or mechanical damage to delicate samples.
Advantages and Disadvantages
The primary advantages of the YR05837 // YR05839 include its versatility, precision, and automated safety protocols. It supports both continuous and pulse modes while its automatic frequency compensation ensures consistent performance. However, its size might pose a constraint for laboratories with limited space, albeit the soundproof box significantly mitigates noise disturbances.
Field Use
This ultrasonic homogenizer is indispensable across various fields such as biotechnology, materials chemistry, and medicine. For instance, it facilitates DNA and protein extraction in molecular biology and is ideal for dispersing carbon nanotubes in chemistry. Its ability to process volumes from 50 ml to 3000 ml makes it a crucial asset for both research and industrial labs.
Recommendations
To ensure optimal performance and longevity, it is advisable to conduct regular maintenance, including cleaning probes and checking the cooling system. For additional inquiries or purchase details, we recommend utilizing the Kalstein Plus platform to generate a quotation that suits your requirements.
Features
This device boasts adjustable ultrasonic power, two operational modes (pulse and continuous), an informative touchscreen display, and a robust titanium alloy probe material for reliable performance.
Technical Specifications
| Model No. | YR05837 | YR05837-1 |
| Working Frequency | 19~25KHz Automatic compensation | |
| Ultrasonic Power | 950W | 650W |
| Processing Capacity | 100~1200ml | 50~800ml |
| Power adjustable | 0~100% | |
| Timer | LCD Touch screen, adjustable from 1s to 99h | |
| Pulser | Digital, closed loop, open loop, 1s to 99min to choose and set | |
| Ultrasonic mode | Pulse mode / Continuous mode | |
| Standard Probe | Φ13mm | Φ6mm |
| Optional Probe | Φ3/6/8/10/16/18mm |
Φ3/6/8/13/16mm
|
| Energy Converter | CV33, PZT lead zirconate titanate piezoelectric ceramics | |
| Probe Material | Titanium Alloy TI-6AL-4V | |
| Cabinet lighting | yes | |
| Lifting table | yes | |
| Machine size | 245*365*245mm | |
| Sound Proof box size | 240*250*390mm | |
| Power Supply | AC220/50Hz,110V/60Hz | |
| Optional Configuration | Magnetic stirring, cooling water circulation system, etc; Computer Software package: RS422 to USB data connection limit (including driver), computer monitoring driver temperature sensor Wrench: used to install and remove the horn Test tube rack | |
| Model No. | YR05838 | YR05839 |
| Working Frequency | 19~25KHz Automatic compensation | |
| Ultrasonic Power | 1200W | 1800W |
| Processing Capacity | 100~2000ml | 100~3000ml |
| Power adjustable | 0~100% | |
| Timer | LCD Touch screen, adjustable from 1s to 99h | |
| Pulser | Digital, closed loop, open loop, 1s to 99min to choose and set | |
| Ultrasonic mode | Pulse mode / Continuous mode | |
| Standard Probe | Φ16mm | Φ20mm |
| Optional Probe | Φ3/6/8/10/13/18/20mm |
Φ3/6/8/10/13/16/18/25mm
|
| Energy Converter | CV33, PZT lead zirconate titanate piezoelectric ceramics | |
| Probe Material | Titanium Alloy TI-6AL-4V | |
| Cabinet lighting | yes | |
| Lifting table | yes | |
| Machine size | 245*365*245mm | |
| Sound Proof box size | 240*250*390mm | |
| Power Supply | AC220/50Hz,110V/60Hz | |
| Optional Configuration | Magnetic stirring, cooling water circulation system, etc; Computer Software package: RS422 to USB data connection limit (including driver), computer monitoring driver temperature sensor Wrench: used to install and remove the horn Test tube rack | |
